SHANGHAI SUNNY ELEVATOR CO.,LTD A safty elevator environment from sunny
6 Years
| Ask Lasest Price | |
| Brand Name : | SUNNY |
| Model Number : | Machine Roomless Elevator |
| Certification : | ISO, CE certificate |
| Price : | $7000-12000 |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 500 Set/ Year |
| Delivery Time : | 15~30 days |
380V/220V Voltage Machine Room Less Passenger Lift Residential Elevator Mrl
| Load(kg) | Person | Speed(m/s) | Door Opening(mm) | Cabin Size(mm) | Shaft Size(AH*BH) | Pit Depth | Head Room Height(mm) |
| 450 | 5 | 0.50 | 700*2100 | 1150*1100 | 1700*1800 | ≥ 1500 | ≥ 3500 |
| 630 | 8 | 1.0-1.5 | 800*2100 | 1300*1250 | 1850*1900 | ≥ 1500 | ≥ 3500 |
| 800 | 10 | 1.0-1.75 | 800*2100 | 1500*1300 | 2050*1950 | ≥ 1500 | ≥ 3500 |
| 10 | 1.0-1.75 | 900*2100 | 1500*1300 | 2050*1950 | ≥ 1500 | ≥ 3500 | |
| 1000 | 13 | 1.0-2.5 | 900*2100 | 1600*1500 | 2150*2150 | ≥ 1500 | ≥ 3500 |
| 1250 | 16 | 1.0-2.5 | 1000*2100 | 1750*1600 | 2300*2250 | ≥ 1500 | ≥ 3500 |
| 1600 | 21 | 1.0-2.5 | 1100*2100 | 2050*1700 | 2600*2450 | ≥ 1500 | ≥ 3500 |
| We can also desgin according customer requirement for approved residential elevators | |||||||
| Basic Functions of Passenger Elevators | |||
| 1 | Full-automatic sorting operation | 31 | CAN communication fault protection |
| 2 | Door closing blocking automatic return function | 32 | Master CPU self-check protection |
| 3 | Overload alarm | 33 | Overheating protection of drive device |
| 4 | Straight operation at full load | 34 | Upward and downward running overspeed protection |
| 5 | Parallel operation | 35 | Contact detection protection of contactor |
| 6 | Directly stop operation | 36 | Leveling fine adjustment |
| 7 | Emergency electric driving of machine room | 37 | Car alarm |
| 8 | Re-initialize the operation | 38 | Stop switch |
| 9 | Automatic stop | 39 | Fire switch |
| 10 | Automatic leveling | 40 | Car roof overhaul |
| 11 | Automatic stop in case of fault | 41 | Exchange landing |
| 12 | Automatic elimination of reverse command | 42 | Power supply filtering function |
| 13 | Automatic return to base station in case of fire alarm | 43 | Speed feedback detection function |
| 14 | Automatic correction of floor location signal | 44 | Brake feedback detection function |
| 15 | Automatic control of lighting fan inside the lift car | 45 | Self-learning of shaft location |
| 16 | Unattended to automatically return to base station | 46 | Diagnosis of shaft self-learning failure |
| 17 | Overspeed protection | 47 | Elimination of false command |
| 18 | Low speed protection | 48 | Door opening/closing button |
| 19 | Ground protection | 49 | Fault self-diagnosis |
| 20 | Anti-slip protection | 50 | Tips for running direction outside the hall and the lift car |
| 21 | Light curtain protection of the door | 51 | Fault history record |
| 22 | Reverse operation protection | 52 | Arbitrary setting in the service layers |
| 23 | Terminal floor protection | 53 | Opening the door outside the hall of this floor |
| 24 | Overload protection of the motor | 54 | Setting of floor display character |
| 25 | Running timeout protection | 55 | Respectively control for the door of the hall and the lift car |
| 26 | Short-circuit protection of door lock | 56 | Outside door opening protection |
| 27 | Fault protection of door opening and closing | 57 | Digital hall/display in the lift car |
| 28 | Running door lock breakage protection | 58 | Emergency lighting in the car in case of power failure |
| 29 | Leveling switch fault protection | 59 | Five-way communication device |
| 30 | Delay protection of car door closing | 60 | Setting of floor display character |
FAQ
1. Is it dangerous for power failure suddenly during the elevator
running?
If it occurs, the elevator will automatically stop due to the
electrical and mechanical safety device. In case of power
failure,elevator brakes will automatically taken. In addition, the
power supply departments such as planned outage, prior notice are
also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of
elevator will automatically restart without any danger. With anti
clamping switch, once the gate touched, this switching action make
the elevator unable to be closed and even reopened. In addition,
closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the
(tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
|
|
