800kg Gearless VVVF With Machine Room Less Passenger Lift Elevator
MACHINE ROOMLESS PASSENGER ELEVATOR
Less Space, More Intelligence
SUNNY machine roomless passenger elevator cancels the machine room,
reduces total area of the elevator equipment and flexibility
utilizes the effective space. It has the strange contemporary sense
and the more beautiful construction outline.
Like normal traction elevators, machine room less elevators uses the conventional steel cord ropes used as the hoisting cables. Some elevator brands are using flat steel rope belts instead of conventional ropes. Manufacturers using these technology claimed that with flat steel belt ropes, it saves much space on the hoistway and to allow a minimum size of the hoisting sheave. With flat steel belts also allows 30% lighter than conventional steel ropes.
Standard Decoration Optional
Persons | Load (kg) | Speed (m/s) | Car dimension (mm) | Door opening size(mm) | Hoist-way size (mm) | Machine room size(mm) | Overhead height (mm) | Pit depth (mm) |
Inner size A x B | Net Door-opening | Width x Depth | Width x Depth | |||||
Passenger elevator | ||||||||
6 | 450 | 1.0 | 1100x1100 | 800 | 1800x1750 | 1800x3700 | 4200 | 1500 |
8 | 630 | 1.0 | 1400x1100 | 800 | 2000x1800 | 3000x3500 | 4500 | 1500 |
1.5 | 4600 | 1600 | ||||||
1.75 | 4700 | 1700 | ||||||
2.0 | 4900 | 2000 | ||||||
10 | 800 | 1.0 | 1400x1350 | 800 | 2000x2000 | 3000x3800 | 4500 | 1500 |
1.5 | 4600 | 1600 | ||||||
1.75 | 4700 | 1700 | ||||||
2.0 | 4900 | 2000 | ||||||
2.5 | 2050x2050 | 3000x3800 | 5500 | 2500 |
Machine roomless passenger elevator construction layout drawing.
FAQ
1. Is it dangerous for power failure suddenly during the elevator
running?
If it occurs, the elevator will automatically stop due to the
electrical and mechanical safety device. In case of power
failure,elevator brakes will automatically taken. In addition, the
power supply departments such as planned outage, prior notice are
also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of
elevator will automatically restart without any danger. With anti
clamping switch, once the gate touched, this switching action make
the elevator unable to be closed and even reopened. In addition,
closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the
(tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
![]() |
