SHANGHAI SUNNY ELEVATOR CO.,LTD A safty elevator environment from sunny
6 Years
| Ask Lasest Price | |
| Brand Name : | SUNNY |
| Model Number : | Bed Medical Elevator |
| Certification : | CE,ISO9001 |
| Price : | $7000-12000 |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 500 Set/ Year |
| Delivery Time : | 15~30 days |
1600kg With Low Noise Customize Patient Bed Elevator Hospital Elevator
Assistive Gearless 630kg Low Noise Patient Bed Medical Elevator with Stainless Steel
What is hospital lift?
This is an assistive device that allows patients in hospitals and
nursing homes and people receiving home health care to be
transferred between a bed and a chair or other similar resting
places, by the use of electrical or hydraulic power.
| Model | Automatic Hospital Bed Elevator lift | ||||
| Loading(Kg) | 630 | 800 | 1000 | 1350 | 1600 |
| Speed(m/s) | 1.0/1.75 | 1.0/1.75/2.0 | 1.0/1.75/2.0 | 1.0/1.75/2.0/2.5 | 1.0/1.75/2.0/2.5 |
| Motor | Gearless Motor | ||||
| Control System | Integrated Controller | ||||
| Door Control | VVVF | ||||
| Opening Width(m) | 800*2100 | 800*2100 | 900*2100 | 1100*2100 | 1100*2100 |
| Headroom(m) | 4.0-4.5 | ||||
| Pit Depth (m) | 1.5 | 1.5-1.7 | 1.5-1.8 | 1.8-2.0 | 1.8-2.0 |
| Total Height(m) | <150m | ||||
| Stop | <56 | ||||
| Brake voltage | DC110V | ||||
| Power | 380V,220V,50HZ/60HZ | ||||
Construction Sketch
FAQ
1. Is it dangerous for power failure suddenly during the elevator
running?
If it occurs, the elevator will automatically stop due to the
electrical and mechanical safety device. In case of power
failure,elevator brakes will automatically taken. In addition, the
power supply departments such as planned outage, prior notice are
also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of
elevator will automatically restart without any danger. With anti
clamping switch, once the gate touched, this switching action make
the elevator unable to be closed and even reopened. In addition,
closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the
(tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
|
|
