    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000kg

    Ask Lasest Price
    Brand Name : SUNNY
    Model Number : Motor Driven Pit Car Lift
    Certification : CE,ISO9001
    Price : $5000-8000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 500 Set/ Year
    Delivery Time : 15~30 days
    • Product Details
    • Company Profile

    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000kg

    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000~2500kg


    CE Certified according to EC machinery directive 2006/42/CE
    Motor driven and chain balance system.
    Fully utilization of underground space.
    Directly park or pick up the car at any level independently.
    Galvanized wave plates platforms, cold bending and strong pressure & humidity resistance.
    Antifalling hooks on 4 posts to ensure safety.
    Flexible designed according to customer requirements, suitable for residential & commercial use.
    Electric sensors to confirm no persons or objects before rising up/down the platforms.


    Product parameters
    Model NOPDK20L2/CPDK25L2/CPDK20L3/C
    Lifting Capacity2000kg2500kg2000kg
    Lighting Height1700mm2100mm1700mm
    Vertical Speed2-3M/Min4-6M/Min2-3M/Min
    Lock ReleaseElectric unlock
    External Dimensiomn5200x2900x2360mm5300x2900x2730mm5200x2900x4060mm
    Drive ModeMotor+Chain
    Vehicle Size5000x1850x1550mm5200x2000x1980mm5000x1850x1550mm
    Parking Mode1 underground,1 on the ground1 on the ground, 2 undergroun
    Parking space23
    Rise/Drop Time70S/60S
    Power Supply/Motor Capacity220V/380V, 50Hz/60Hz,1Ph/3Ph,3.7Kw220V/380V, 50Hz/60Hz,1Ph/3Ph,5.5Kw



    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000kg


    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000kg


    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000kg


    Motor Driven Pit Car Lift Parking System PDK Auto Parking Lift For Home 2000kg


    FAQ
    1. Are the elevator wire ropes durable?
    The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
    2. Is it dangerous for power failure suddenly during the elevator running?
    If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
    3. Will us be hurt when it closed suddenly?
    In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
    4. How the elevator running?
    Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
    5. Is the escalator installation complicated?
    We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
    6. Do you have any cerifications?
    Yes, we do with ISO9001 / CCC / CE Certificates for u.
