SHANGHAI SUNNY ELEVATOR CO.,LTD A safty elevator environment from sunny
6 Years
| Ask Lasest Price | |
| Brand Name : | SUNNY |
| Model Number : | Passenger elevator |
| Certification : | 3C,CE |
| Price : | $7000~12000 |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 500 Set/ Year |
| Delivery Time : | 15~30 days |
MRL Passenger Elevator With Golden Cabin For Passenger Lift In Commercial Buildings
800kg MRL Golden Cabin Residential Home Elevators AC Driven
pseenger elevator with machine room:
| Load | Speed | Car size | Door opening size | Shaft size | Maximum landing | Maximum lifting height | MRH mm Net height of machine room | ||||||
| kg | m/s | CW | CD | CH | OP | OPH | HW | HD | K | S | |||
| 630 | 1 | 1400 | 1100 | 2500 | 800 | 2100 | 1850 | 1750 | 4250 | 1400 | 20 | 60 | 2500 |
| 1.5 | 4350 | 1450 | 24 | 72 | |||||||||
| 1.75 | 4400 | 1500 | 30 | 90 | |||||||||
| 800 | 1 | 1400 | 1350 | 2500 | 900 | 2100 | 1960 | 2000 | 4300 | 1400 | 20 | 60 | 2500 |
| 1.5 | 4400 | 1450 | 24 | 72 | |||||||||
| 1.75 | 4450 | 1500 | 30 | 90 | |||||||||
| 2 | 2000 | 2050 | 4900 | 1750 | 40 | 120 | |||||||
| 2.5 | 5100 | 1950 | 32 | 130 | |||||||||
| 1000 | 1 | 1600 | 1400 | 2500 | 900 | 2100 | 2050 | 2050 | 4300 | 1400 | 20 | 60 | 2550 |
| 1.5 | 4400 | 1450 | 24 | 72 | |||||||||
| 1.75 | 4450 | 1500 | 30 | 90 | |||||||||
| 2 | 2200 | 2100 | 4900 | 1750 | 40 | 120 | |||||||
| 2.5 | 5100 | 1950 | 40 | 130 | |||||||||
| 3.5 | 2300 | 2200 | 5600 | 3400 | 60 | 180 | |||||||
| 1150 | 1 | 2000 | 1500 | 2500 | 1100 | 2100 | 2500 | 2150 | 4550 | 1550 | 20 | 60 | 2500 |
| 1.5 | 4700 | 1600 | 24 | 72 | |||||||||
| 1.75 | 4750 | 1650 | 30 | 90 | |||||||||
| 2 | 4900 | 1750 | 40 | 120 | |||||||||
| 2.5 | 5100 | 1950 | 40 | 130 | |||||||||
| 3.5 | 2700 | 2150 | 5600 | 3400 | 60 | 180 | |||||||
| 1350 | 1 | 2000 | 1500 | 2500 | 1100 | 2100 | 2500 | 2200 | 4550 | 1550 | 20 | 60 | 2500 |
| 1.5 | 4700 | 1600 | 24 | 72 | |||||||||
| 1.75 | 4750 | 1650 | 30 | 90 | |||||||||
| 2 | 4900 | 1750 | 40 | 120 | |||||||||
| 2.5 | 5100 | 1950 | 40 | 130 | |||||||||
| 3.5 | 2700 | 2400 | 5600 | 3400 | 60 | 180 | |||||||
| 1600 | 1 | 2000 | 1700 | 2500 | 1100 | 2100 | 2500 | 2400 | 4550 | 1600 | 20 | 60 | 2500 |
| 1.5 | 4700 | 1700 | 24 | 72 | |||||||||
| 1.75 | 4750 | 1750 | 30 | 90 | |||||||||
| 2 | 4900 | 1800 | 40 | 120 | |||||||||
| 2.5 | 5100 | 1950 | 40 | 130 | |||||||||
| 3.5 | 2700 | 2600 | 5600 | 3400 | |||||||||
Construction Sketch
STANDARD CONFIGURATION
FAQ
1. Is it dangerous for power failure suddenly during the elevator
running?
If it occurs, the elevator will automatically stop due to the
electrical and mechanical safety device. In case of power
failure,elevator brakes will automatically taken. In addition, the
power supply departments such as planned outage, prior notice are
also operating.
2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of
elevator will automatically restart without any danger. With anti
clamping switch, once the gate touched, this switching action make
the elevator unable to be closed and even reopened. In addition,
closing force is also available here.
3. How the elevator running?
Elevators are operated with a counterweight wire rope through the
(tractor) traction drive, making ups and downs on the guide rail.
4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
|
|
